Tech Specs
Bucket
| Dump Clearance At Max Raise | 2.91 ft in |
|---|---|
| Bucket Capacity – Heaped | 1.44 yd3 |
| Bucket Capacity – Struck | 1.18 yd3 |
| Bucket Width | 7.22 ft in |
| Breakout Force | 12364 lb |
Dimensions
| Length With Bucket On Ground | 20.15 ft in |
|---|---|
| Hinge Pin – Max Height | 10.47 ft in |
| Reach At Max Lift And Dump | 1.87 ft in |
Specifications
Engine
| Number Of Cylinders | 5 |
|---|---|
| Fuel System Control | Electronically controlled unit injection pump |
| Engine Make | John Deere Power Tech |
| Engine Model | 5030T |
| Air Cleaner | Dual safety element dry type |
| Max Torque | 195 lb ft |
| Displacement | 177 cu in |
| Aspiration | Turbocharged |
Operational
| Operating Voltage | 24 V |
|---|---|
| Alternator Supplied Amperage | 65 amps |
| Tire Size | 405/70R20 |
Hydraulic System
| Pump Flow Capacity | 25.1 gal/min |
|---|---|
| Raise Time | 5.3 sec |
| Dump Time | 1.6 sec |
| Lower Time | 4.5 sec |
Loader Attachment Options:
- Bucket
- Grapple
- Forks
